440 Backhoe Loader

Net Power - SAE J1349:2011104hp

Bore4.13in

Stroke5in

Displacement268in³

Net Peak Power - 1,800 rpm - ISO 924973hp

Ratings at 2,200 rpm - Gross Power SAE J1995118hp

Gross Power - SAE J1995:201474hp

Net Peak Power Rating - ISO 9249 at 1,800 rpm108hp

Net Torque Rise - 1,200 rpm88%

Net Peak Power - 1,800 rpm - EEC 80/126973hp

Net Power - 2,200 rpm - SAE J134968hp

Gross Power - ISO 1439674hp

Rated Net Power - 2,200 rpm - EEC 80/126969hp

Net Power Rating at 2,200 rpm - ISO 9249104hp

Engine ModelC4.4 ACERT 87 kW (116 hp) Electronic – Turbo Intercooled

Ratings at 2,200 rpm - Gross Power ISO 14396116hp

Net Peak Power - 1,800 rpm - SAE J134972hp

Net Torque Rise - 1,400 rpm - SAE J1349360ft·lbf

Net Peak Power Rating - SAE J1349 at 2,100 rpm108hp

Rated Net Power - 2,200 rpm - ISO 924968hp

Net Torque Rise - 1,400 rpm44%

Power Rating Conditions - No De-Rating Required Up To7500ft

Net Power Rating at 2,200 rpm - SAE J1349104hp

EmissionsEngine meets U.S. EPA Tier 4 Final emission standards.

Net Peak Torque SAE J1349307ft·lbf

NoteNo derating required up to 2286 m (7,500 ft).

Dig Depth - Standard15.5ft

Operating Weight - Maximum29321lb

Cab - ROPS/FOPS359lb

Air Conditioning101lb

Operating Weight - Estimated*21544lb

MP Bucket (1.00 m3/1.31 yd3) - With Fold-Over Forks2018lb

Loader Bucket - 1.34 m³ (1.75 yd³) MP ED (Hook-On)+160 kg (+353 lb)

Cab, ROPS/FOPS+243 kg (+536 lb)

Loader Bucket - 1.34 m³ (1.75 yd³) MP HD (Pin-On)+214 kg (+472 lb)

Extendible Stick+301 kg (+664 lb)

MP Bucket (1.00 m3/1.31 yd3) - Without Fold-Over Forks3622lb

Loader Quick Coupler+250 kg (+551 lb)

Front Counterweight - Counterweights - Option 1255lb

Note (2)GP = General Purpose

Loader Bucket - 1.53 m³ (2.0 yd³) GP (Hook-On)–73 kg (–162 lb)

Note (4)HD = Heavy Duty

Front Counterweight - Counterweights - Option 2530lb

Operating Weight - Maximum - ROPS Capacity29321lb

Counterweight1102lb

Backhoe Quick Coupler+87 kg (+192 lb)

Loader Bucket - 1.34 m³ (1.75 yd³) MP HD (Hook-On)+85 kg (+187 lb)

Loader Bucket - 1.34 m³ (1.75 yd³) MP ED (Pin-On)+290 kg (+639 lb)

Note (1)*Machine equipped with 340/80-18 front and 500/70-24 rear, AWD, OROPS, 1.34 m³ (1.75 yd³) general purpose bucket with bolt-on cutting edge, standard stick, 610 mm (24"") severe-duty backhoe bucket.

Loader Bucket - 1.53 m³ (2.0 yd³) GP (Pin-On)+80 kg (+176 lb)

Loader Bucket - 1.34 m³ (1.75 yd³) GP (Hook-On)–150 kg (–331 lb)

Note (5)ED = Extreme Duty

Note (3)MP = Multi Purpose

Front Counterweight - Counterweights - Option 31015lb

Rear Counterweight198lb

Pump TypeVariable Flow, Axial Piston

System Pressure - Loader3800psi

Pump Capacity at 2,200 rpm58.1gal/min

System Pressure - Hitch/Box Scraper2973psi

TypeClosed Center

System Pressure - Backhoe3800psi

Dig Depth - Standard3in

Autoshift Transmission - Reverse - 1st3.7mile/h

Power Shuttle Transmission - Forward 3rd13mile/h

Power Shuttle Transmission - Reverse 2nd5.5mile/h

Autoshift Transmission - Forward - 6th24.4mile/h

Power Shuttle Transmission - Reverse 4th23mile/h

Autoshift Transmission - Reverse - 3rd16.7mile/h

Power Shuttle Transmission - Forward 2nd5.5mile/h

NoteTravel speeds of backhoe loader in two wheel drive at full throttle, when equipped with 500/70-24 rear tires.

Autoshift Transmission - Forward - 1st3.7mile/h

Autoshift Transmission - Forward - 3rd7.7mile/h

Autoshift Transmission - Forward - 4th12.2mile/h

Power Shuttle Transmission - Forward 4th23mile/h

Power Shuttle Transmission - Reverse 1st3.4mile/h

Autoshift Transmission - Forward - 2nd5.9mile/h

Power Shuttle Transmission - Forward 1st3.4mile/h

Autoshift Transmission - Reverse - 2nd7.7mile/h

Autoshift Transmission - Forward - 5th16.7mile/h

Power Shuttle Transmission - Reverse 3rd13mile/h

Hydraulic System23.8gal (US)

Engine Oil - With Filter2.3gal (US)

Rear Axle - Planetaries0.4gal (US)

Cooling System with Cab Heater6gal (US)

Hydraulic System (Minimum)31.7gal (US)

Transmission - Power Shuttle - 2WD4gal (US)

Cooling System with Air Conditioning4.4gal (US)

Fuel Tank42.3gal (US)

Transmission (Autoshift) - AWD, Autoshift4.8gal (US)

Planetaries0.2gal (US)

Rear Axle4.4gal (US)

Transmission - Power Shuttle - 4WD4gal (US)

Front Axle (Center Housing)2.9gal (US)

Rear Axle (Center Housing)4.4gal (US)

Hydraulic Tank (Nominal)14.3gal (US)

Front Axle (4WD) - Planetaries0.2gal (US)

Diesel Exhaust Fluid (DEF)5gal (US)

Front Axle (4WD)2.9gal (US)

NoteRequires ultra-low sulfur fuel less than or equal to 15 ppm fuel sulfur

Hydraulic Tank10.6gal (US)

Rod Diameter1.65in

Stroke9.29in

Turning Circle (inner wheel not braked) - Outside Front Wheels27.33ft

NoteAWD cylinder, one (1) double-acting.

Bore3.35in

Turning Circle (inner wheel not braked) - Outside Widest Loader Bucket37.75ft

Power SteeringHydrostatic HMU

TypeFront Wheel

Axle Oscillation11°

Turning Circle - (inner wheel not braked) - Outside Front Wheels26.8ft

Turning Circle - (inner wheel not braked) - Outside Widest Loader Bucket36ft

Front Axle, AWD - Static50565lb

Front Axle (4WD) - Dynamic20233lb

Rear Axle - Static50565lb

Rear Axle - Dynamic20225lb

Front Axle, AWD - Dynamic20225lb

Front Axle (4WD) - Static50582lb

Standard Configuration of Front/Rear TiresFront: 12.5 80/16.9; Rear: 16.9-24

Standard Stick - GP Loader Bucket - 4WD255lb

Standard Stick - MP Loader Bucket - 4WDno counterweight

Standard

4572 mm (15 ft) center pivot excavator style backhoe

Adjustable auxiliary flow controls, loader and backhoe

Air cleaner

Alarm, back-up

Alternator, 150 amp

Audible system fault alarm

Automatic Engine Speed Control (AESC)

Autoshift transmission with six (6) forward and three (3) reverse gears and neutral safety switch

Backhoe Safety Manual

Battery Box, external, lockable

Battery disconnect switch

Battery, maintenance-free, 1,000 CCA

Boom transport lock

Brace, lift cylinder

Brake, SAHR secondary parking

Brakes, hydraulically boosted, oil disc, dual pedals, interlocking

Canopy, ROPS/FOPS

Cat cushion swing system

CD-ROM Parts Manual

Coat restraint

Coolant/antifreeze, extended life

Counterweight, bumper, 500 kg (1,102 lb)

Diagnostic port for engine, machine and gauge cluster Electronic Control Modules

Differential lock, loader joystick

Dome light (cab only)

Engine enclosure, sound suppression removal panels

Engine, Cat C4.4 ACERT (Direct Injection Turbocharged), meets Tier 4 Final/Stage IV emission standards, selective catalyst reduction, diesel oxidation catalyst (DOC)

Face seals, O-ring

Fan, suction and guard

Fast reversing shuttle, all gears

Fenders, rear

Filters, bowl and cartridge: fuel, hydraulic fluid

Filters, spin-on: engine oil, transmission oil, water separator

Flashing hazards/signal lights

Floor mat

Four Wheel Drive/Brake Mode Selector

Fuel tank, fully enclosed

Fully hinged front grill for cooling package cleaning access

Ground level fuel fill and DEF fill

High ambient cooling package

Hood lock, inside cab

Hydraulic hose, XT^™

Hydraulic oil cooler

Hydraulic oil level sight gauge

Hydraulic valves, backhoe six (6) function

Hydraulic valves, loader three (3) function

Hydraulics, load sensing with variable displacement piston pump and flow sharing valve

Indicator lights: hydraulic implement lockout, hydraulic filter bypass, water in fuel, operator presence, remote dial throttle active, air filter blocked, engine warning, machine locked (if equipped), warning lamp, emissions module malfunction, low battery/charging system warning, high hydraulic oil temperature; LCD warnings: engine oil pressure, service due, high coolant temperature, auto idle shutdown, high torque converter temperature

Instrument panel lights

Joystick controls: electrohydraulic controls with pattern changer valve

Key start/stop system

LCD operator screen

Lights, working (four [4] front, four [4] rear)

Loader joystick, self-leveling, return-to-dig, transmission disconnect switch, Forward/Neutral/Reverse Switch, MP Auxiliary roller

Loader, single tilt

Machine Security System integrated into LCD operator display

Mirror, rearview

One-touch low idle

Open circuit breather

Operations and Maintenance Manual

Pattern changer, in cab

Power receptacle, 12 volt, one (1) internal + one (1) USB, two (2) external

Product Link^™

Radio ready (Cab)

Rubber impact strips on radiator guards

Seat belt, retractable, 51 mm (2 in)

Seat mounted controls

Seat, air suspension with armrest

Stabilizer pads, reversible

Stabilizers, electrohydraulic, auto-up function

Starting system, glow plugs

Steering knob

Steering, hydrostatic

Stop and tail lights

Storage compartment (Cab/Canopy), lockable

Storage tray, electronics and miscellaneous items

Swing transport lock

Throttle, hand and foot, electronic

Tilt steering wheel (Canopy), Tilt/telescoping (Cab)

Tire Valve Stem Protection

Tires

Torque converter

Transmission neutralizer switch

Transport tie-downs

Vandalism locks, four (4)

Vandalism protection, gauge cover (Canopy)

Warning horn, electric

Optional

Battery, additional, 1,000 CCA

Cab, deluxe with air conditioning

Cold weather fuel (–30° C/–22° F)

Cold weather package, including additional battery, engine block heater, radiator antifreeze, cold weather fuel (–30° C/–22° F) and mounting for an ether bottle

Fenders, front with integral steps

Guard, boom protection plate

Guard, stabilizer, rock

Guard, stabilizer, stab leg bottom

Hydraulic lines, combined function auxiliary

Hydraulic valves, loader quick coupler

Lights, LED work lights, wide and spot

Loader, Quick Coupler

Quick Coupler, backhoe, hydraulic, dual lock

Quick Coupler, backhoe, manual, dual lock

Quick Coupler, backhoe, pin lock

Radio and CD player, Bluetooth^®

Ride Control

Rotating beacon, magnetic mount

Seat belt, 75 mm (3 in)

Seat, heated

Stick, extendible

Transmission, Autoshift with lock-up torque converter

Work Tool Attachments such as buckets, forks, material handling arms, augers, hammers, brooms, cold planers and vibratory plate compactors. See your Cat dealer for more information.
