340 Long Reach Excavator

More

Machine Information

Specifications

Engine
Engine Power - ISO 9249
311 HP
Engine Model
Engine Power - ISO 14396
314 HP
Bore
5 in
Stroke
6 in
Displacement
568 in³
Hydraulic System
Main System - Maximum Flow
Maximum Pressure - Equipment
5076 psi
Maximum Pressure - Equipment - Lift Mode
5511 psi
Maximum Pressure - Travel
5076 psi
Maximum Pressure - Swing
4264 psi
Swing Mechanism
Swing Speed
8.75 r/min
Maximum Swing Torque
106228 ft·lbf
Weights
Operating Weight
96700 lb
Service Refill Capacities
Fuel Tank Capacity
158.5 gal (US)
Cooling System
10.5 gal (US)
Engine Oil
8.5 gal (US)
Swing Drive
4.8 gal (US)
Final Drive - Each
2.1 gal (US)
Hydraulic System - Including Tank
98.5 gal (US)
Hydraulic Tank
42.5 gal (US)
DEF Tank
21.1 gal (US)
Dimensions
Boom
Stick
Bucket
Shipping Height - Top of Cab
11.2 ft
Handrail Height
11.1 ft
Track Gauge
9.6 ft
Shipping Length
50.2 ft
Tail Swing Radius
11.6 ft
Counterweight Clearance
4.8 ft
Ground Clearance
2.4 ft
Track Length
15.5 ft
Track Length to Center of Rollers
13.3 ft
Transport Width
12 ft
Working Ranges & Forces
Maximum Digging Depth
42.8 ft
Boom
Stick
Maximum Reach at Ground Level
59.3 ft
Maximum Loading Height
41.9 ft
Minimum Loading Height
10.5 ft
Maximum Depth Cut for 2440 mm (8 ft) Level Bottom
35 ft
Bucket Digging Force - ISO
31590 lbf
Stick Digging Force - ISO
20750 lbf
Bucket
Maximum Cutting Height
51.2 ft

Additional Parts

Standard Equipment
NOTE:
CAB
ENGINE
HYDRAULIC SYSTEM
UNDERCARRIAGE AND STRUCTURES
BOOM AND STICK
ELECTRICAL SYSTEM
CAT TECHNOLOGY
SERVICE AND MAINTENANCE
SAFETY AND SECURITY
Optional Equipment
ENGINE
HYDRAULIC SYSTEM
UNDERCARRIAGE AND STRUCTURES
CAT TECHNOLOGY
SERVICE AND MAINTENANCE
SAFETY AND SECURITY
