D11 Dozer

Engine ModelCat® C32

Engine Power - Net SAE J1349/ISO 9249 - Forward850hp

Displacement1959in³

Engine Power - Net SAE J1349/ISO 9249 - Reverse955hp

Note (1)*Excludes all fan losses.

Note (2)Engine ratings apply at 1,800 rpm.

Note (3)Net power advertised is the power available at the flywheel when the engine is equipped with air cleaner, muffler, alternator, fan, and engine emissions controls as required.

Operating Weight229800lb

Operating Weight - Carrydozer250665lb

Note (1)D11 Operating Weight: Includes blade tilt cylinders, coolant, lubricants, full fuel tank, ROPS, FOPS cab, 11U ABR bulldozer, single-shank ripper with pin-puller, fast fuel, 710 mm (28 in) ES shoes, and operator.

Note (2)D11 CD Operating Weight: Includes lubricant, coolant, full fuel tank, 915 mm (36 in) extreme service shoes, 11 Carrydozer, singleshank ripper, and operator.

Semi-Universal (SU)* Capacity35.6yd³

Semi-Universal (SU)* Width Over Endbits219.8in

U-Blade Capacity45yd³

U-Blade Width249.6in

Reclamation Universal - Blade capacity (SAE J1265)55yd³

Reclamation Universal - Width with blade (over end bits)251.8in

Carry Dozer - Blade capacity (SAE J1265)57yd³

Carry Dozer - Width with blade (over end bits)263.9in

Engine ModelCat® C32

Displacement1959in³

Engine Power - Net SAE J1349/ISO 9249 - Forward850hp

Engine Power - Net SAE J1349/ISO 9249 - Reverse957hp

Note (1)*Excludes all fan losses.

Note (2)Engine ratings apply at 1,800 rpm.

Note (3)Net power advertised is the power available at the flywheel when the engine is equipped with air cleaner, muffler, alternator, fan, and engine emissions controls as required.

Fuel Tank - Total Volume500gal (US)

Fuel Tank - Usable Volume475gal (US)

Pump TypeVariable displacement piston pump

Combined Pump Output - Implement177gal/min

Shoe TypeExtreme Service

Width - Shoe28in

Width - Shoe - CD36in

Shoes/Side41

Grouser Height4in

Pitch12.5in

Ground Clearance*30.6in

Track Gauge114in

Length - Track on Ground175in

Ground Contact Area9781in²

Ground Contact Area - CD12605in²

Track Rollers/Side8

Number of Carrier Rollers1 per side (optional)

1.0 Forward2.5mile/h

2.0 Forward4.4mile/h

3.0 Forward7.6mile/h

1.0 Reverse3mile/h

2.0 Reverse5.3mile/h

3.0 Reverse9.1mile/h

Drawbar Pull - 3 Forward46250ft·lbf

Drawbar Pull - 1 Forward148200ft·lbf

Drawbar Pull - 2 Forward82300ft·lbf

Maximum penetration force * (shank vertical)66000lb

Maximum penetration depth (standard tip)63.5in

Pryout Force148510lb

Maximum penetration force * (shank vertical)66110lb

Maximum penetration depth (standard tip)85.5in

Pryout Force148510lb

Overall Beam Width131.1in

Maximum Penetration Force - Shank Vertical77350lb

Maximum Penetration - Standard Tip43.3in

Pry-Out Force - Multi-Shank Ripper with One Tooth145640lb

Width at Outside of Track (710 mm Track Shoe)149.8in

Length with SU-Blade** - No rear attachment345.1in

Overall Length SU-Blade and SS Ripper**421.7in

Cooling System46.8gal (US)

Cooling System Refill - Tier 2 Equivalent Engine41.7gal (US)

Engine Crankcase35.1gal (US)

Power Train120gal (US)

Power Train - Refill Volume103.3gal (US)

Final Drive - Each12.4gal (US)

Roller Frames - Each24.8gal (US)

Hydraulic Tank42.2gal (US)

Hydraulic System Tank and Chassis64.7gal (US)

Hydraulic System Chassis + Blade and Ripper (Standard)117.6gal (US)

Hydraulic System Chassis + Blade and Ripper (Carrydozer)143.4gal (US)

ROPSRollover Protective Structure (ROPS) meets the following criteria: ISO 3471:2008

FOPSFalling Objects Protective Structure (FOPS) meets the following criteria: ISO 3449:2005 LEVEL II

Sound (1)The exterior sound pressure level for the standard machine (ISO 6396:2008) is 116 dB(A) (sound suppressed).

Sound (2)The operator equivalent sound pressure level (ISO 6396:2008) is 78 dB(A) (sound suppressed).

Ground Clearance*31.4in

Track Gauge114in

Width at Outside of Track (710 mm Track Shoe)142in

Height (ROPS/canopy)*185.9in

Length of Track on Ground175in

Length with SU-Blade** - No rear attachment337.8in

Overall Length SU-Blade and SS Ripper**414.4in

Note*Includes grouser height for total dimensions on hard surfaces.

Note (1)The air conditioning system on this machine contains the flourinated greenhouse gas refrigerant R134a (Global Warning Potential = 1430). The system contains 2.1 kg (4.6 lb) of refrigerant which has a CO2 equivalent of 3.003 metric tonnes (3.31 tons)

Standard

ROPS/FOPS, Sound-Suppressed Cab

High-Definition Primary Touchscreen Display

Visibility – Rearview Mirrors

Air Conditioner and Heater with Automatic Climate Control

Seat – Cloth with Air suspension

Cab Glass – Single-Pane Tinted Safety

Cab Access – Blade Push Arm Steps and Grab Handle

Optional

MineStar^™ Terrain Display

Visibility – Dual Camera

Visibility – Four Cameras, 360 Degree View

Seat – Heated, Cooled, Adjustable Lumbar and Bolsters

Cab Glass – Dual-Pane Laminated Impact Safety

Cab Glass – High-Pressure Safety (40 psi/275 kPa)

Cab Access – Powered Ladder

Standard

VIMS

Automated Blade Assist (ABA)

Cat Product Link^™ Elite (cellular)

Optional

AutoCarry^™

Auto Ripper Control

Cat Terrain with 3D Blade Control

Cat Terrain Ready

Cat Product Link Elite Dual Mode (cellular + satellite)

Cat Command for Dozing Ready

Standard

Cat C32 Engine – U.S. EPA Tier 4 Final or Tier 2 Equivalent

High-Performance Single-Plane Cooling Module

Stator Clutch Torque Divider – Electronic Control

Powershift Transmission – Three-Speed Electronic Shift

Optional

Hydraulic Cooling Fan – Automatic Reversing

Standard

Suspension Type Undercarriage

Sleeve Bearing Track

Lifetime-Lubricated Rollers and Idlers

Track Shoe (ES): 710 mm (28 in) Width

Optional

Track Shoes (ES): 810/915 mm (32/36 in) Width (various configurations)

Track Links – High Abrasion – Tall Link

Track Links – Heavy Duty XL – Duralink

Track Shoe – Abrasion Resistant

Track Shoe – Anti-Packing Round Hole

Abrasion Rollers and Idlers

Cold Weather Rollers and Idlers

Sound Suppression Undercarriage

Carrier Roller

Standard

Electronically Controlled, Load-Sensing Dozer Lift and Tilt

Electronically Controlled, Load-Sensing Ripper Lift and Pitch

Dozer Blade – Dual Tilt

Electronically Enabled Blade – Quick Drop

Optional

Carrydozer Hydraulics

Dozer Extended Blade Pitch

Ripper Pin Puller

Standard

24V Electric Start, Dual Starters

Batteries – 4 × 4,200-Amp Hour, 12V

Battery Isolation

Lights – Halogen – 13 Positions

Optional

Battery Isolation – Dual Pole

Lights – LED – Premium Package

Standard

Ecology Fluid Drains – All Compartments

Hinged Bottom Guards

High-Speed Oil Change – Engine and Transmission

Ground-Level Fast Fuel Fill

Ground-Level Electrical Service Station

S·O·SSM Fluid Sampling Ports

Diagnostic Connector

Optional

Sound Reduction Sealed Bottom Guards

Ground-Level Fluid Fill and Drain

Ripper Lubrication – Autolube with Ground-Level Fill

Ripper Lubrication – Grouped – Ground-Level Fill

Optional

Ripper – Single Shank with Pin Puller

Ripper – Single Shank Pushblock with Pin Puller

Ripper – Single Shank with Pin Puller – Heavy

Ripper – Multi Shank (three shank)

Ripper – Multi Shank – Heavy (three shank)

Ripper – Multi Shank Leach Pad with Pin Puller

Ripper – Multi Shank – Coal (five shank)

Counterweight – Rear

Drawbar with Counterweight

Optional

Semi-Universal (27.2 m³/35.6 yd³)

Universal (34.4 m³/45.0 yd³)

Carrydozer (43.6 m³/57 yd³)

Reclamation Universal (42 m³/55 yd³)

Reclamation Universal (53.5 m³/70 yd³)

Coal Universal (75 m³/98.0 yd³)

Coal Universal (65 m³/85.5 yd³)

Optional

Fire Suppression Ready

Fire Suppression Installed
