D9 Dozer

The Cat® D9 Dozer is a versatile machine designed to be used in a variety of applications, such as ripping overburden, production dozing, stockpiling, winching, site maintenance, fleet support and reclamation. It can be equipped with a number of blade options to meet site-specific needs. A highly reliable and fully integrated Cat machine, the D9’s components work together to ensure top performance, high availability and long life. Features like the new stator clutch torque converter boost efficiency and reduce fuel usage, and a number of onboard technology solutions further increase efficiency and performance. These improvements — and more — make the D9 a dozer that delivers a lower overall cost per unit of material moved.

Request a Quote

Engine ModelCat® C18

Engine Power - Net SAE J1349/ISO 9249452hp

Bore5.7in³

Stroke7.2in

Displacement1106in³

Engine Power - Gross SAE J1995487hp

Engine Power - ISO 14396479hp

EmissionsU.S. EPA Tier 2 or Tier 3 equivalent

Note (1)All engine ratings apply at 1,750 rpm.

Note (2)No derating required up to 4267 m (14,000 ft) altitude.

Operating Weight110225lb

Shipping Weight84373lb

Note (1)D9 Operation Weight includes hydraulic controls, blade tilt cylinder, coolant, lubricants, full fuel tank, ROPS, FOPS cab, SU Blade, Single-Shank Ripper, 610 mm (24 in) ES shoes and operator.

Note (2)D9 Operation Weight includes base machine chassis with cab, pivot shaft, roller frames, track and ROPS.

Shoe TypeExtreme Service

Width - Shoe24in

Shoes/Side43

Grouser Height3.3in

Pitch9.4in

Ground Clearance18.1in

Track Gauge88.6in

Length - Track on Ground136.6in

Ground Contact Area45.6ft²

Track Rollers/Side8

Number of Carrier Rollers1 per side (optional)

ROPSRollover Protective Structure (ROPS) meets the following criteria ISO 3471:2008.

FOPSFalling Object Protective Structure (FOPS) meets the following criteria ISO 3449:2005 LEVEL II.

SoundThe average dynamic spectator sound power level when ISO 6395:2008 is used to measure the value for a machine is 116 dB(A). The measurement was conducted at 70% of the maximum engine cooling fan speed. The sound level may vary at different engine cooling

Sound (1)The average dynamic operator sound pressure level when ISO 6396:2008 is used to measure the value for an enclosed cab is 78 dB(A). The measurement was conducted at 70% of the maximum engine cooling fan speed. The sound level may vary at different engine c

Sound (2)Hearing protection may be needed when the machine is operated with an open operator station for extended periods, in a noisy environment, or with a cab that is not properly maintained.

Steering TypeDifferential

Brake TypeSpring Applied Wet Disc

Brake Diameter15.5in

Brake Count8

Engine ModelCat® C18

Bore5.7in³

Stroke7.2in³

Displacement1106in³

Engine Power - Gross SAE J1995477hp

Engine Power - ISO 14396468hp

Engine Power - Net SAE J1349/ISO 9249440hp

EmissionsU.S. EPA Tier 4 / EU Stage V

Note (1)All Engine ratings apply at 1,750 rpm.

Note (2)No derating required up to 2499 m (8,200 ft).

Fuel Tank (Splash Fill)254gal (US)

DEF Tank (Tier 4 only)9.5gal (US)

Fuel Tank (Fast Fill)248gal (US)

Cooling System21gal (US)

Engine Crankcase*10gal (US)

Powertrain40gal (US)

Final Drives (each)4gal (US)

Roller Frames (each)12gal (US)

Pivot Shaft Oil8gal (US)

Hydraulic System Tank24gal (US)

Note*With oil filters.

Note 2Biodiesel blends up to B20 (20% blend by volume) are acceptable when blended with 15 ppm (mg/kg) sulfur or less ULSD. B20 should meet ASTM D7467 specification (biodiesel blend stock should meet Cat biodiesel spec, ASTM D6751 or EN 14214). Cat DEO-ULSTM or

Note 3All non-road Tier 4 Final diesel engines are required to use only ultra-low sulfur diesel (ULSD) fuels containing 15 ppm (mg/kg) sulfur or less.

Note 4Diesel Exhaust Fluid (DEF) used in Cat Selective Catalytic Reduction (SCR) systems must meet the requirements outlined in the International Organization for Standardization (ISO) standard 22241.

Pump TypePiston-type geared to flywheel

Pump Output - Steering96gal/min

Fan Pump21gal/min

Tilt Cylinder Flow - Rod End Flow53gal/min

Tilt Cylinder Flow - Head End Flow53gal/min

Lift Cylinder Relief Valve Setting3800lbf/in

Tilt Cylinder Relief Valve Setting2799psi

Ripper - Lift - Relief Valve Setting3800psi

Ripper - Pitch - Relief Valve Setting3800psi

Steering System - Pressure5874psi

Tank Capacity24gal/min

Note (1)Steering pump output measured at 1,750 engine rpm and 30 000 kPa (4,350 psi).

Note (2)Implement pump output measured at 1,750 engine rpm and 20 000 kPa (2,900 psi).

Note (3)Fan pump output measured at 1,750 engine rpm and 17 000 kPa (2,470 psi)

Air ConditioningThe air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430) the system contains 2.1 kg of refrigerant which has a CO2 equivalent of 3.003 metric tonnes.

1.0 Forward2.2mile/h

2.0 Forward3.9mile/h

3.0 Forward6.8mile/h

1.0 Reverse2.7mile/h

2.0 Reverse4.8mile/h

3.0 Reverse8.4mile/h

TypePlanetary powershift

Blade Capacity (SAE J1265)17.8yd³

Blade Width (over end bits)171.3in

Blade Height76.1in

Maximum Digging Depth23.9in

Ground Clearance at Full Lift56in

Maximum Tilt37in

Blade Weight10587lb

Total Operating Weight* (with blade and single-shank ripper)110205lb

Note* Total Operating Weight includes: single tilt hydraulics, coolant, lubricants, full fuel tank, ROPS, FOPS cab, 610 mm (24 in) ES track shoes and the noted blade and ripper type.

Blade Capacity (SAE J1265)21.7yd³

Blade Width (over end bits)184.3in

Blade Height76.1in

Maximum Digging Depth23.9in

Ground Clearance at Full Lift56in

Maximum Tilt39.9in

Blade Weight12016lb

Total Operating Weight* (with blade and single-shank ripper)111362lb

Note*Total Operating Weight includes: single tilt hydraulics, coolant, lubricants, full fuel tank, ROPS, FOPS cab, 610 mm (24 in) ES track shoes and the noted blade and ripper type.

Maximum penetration force * (shank vertical)35520lbf

Maximum penetration depth (standard tip)48.5in

Pryout Force74637lbf

Maximum Clearance Raised - Under Tip, Pinned in Bottom Hole34.7in

Number of Pockets1

Weight10701lb

Total Operating Weight* (with SU Blade and noted ripper)110205lb

Note*Total Operating Weight includes: single tilt hydraulics, coolant, lubricants, full fuel tank, ROPS, FOPS cab, 610 mm (24 in) ES track shoes and the noted blade and ripper type.

Maximum penetration force * (shank vertical)38667lbf

Maximum penetration depth (standard tip)68in

Pryout Force74412lbf

Maximum Clearance Raised - Under Tip, Pinned in Bottom Hole32.2in

Number of Pockets1

Weight10981lb

Total Operating Weight* (with SU Blade and noted ripper)110485lb

Note*Total Operating Weight includes: single tilt hydraulics, coolant, lubricants, full fuel tank, ROPS, FOPS cab, 610 mm (24 in) ES track shoes and the noted blade and ripper type.

Maximum Penetration Force - Shank Vertical34621lbf

Maximum Penetration - Standard Tip31.4in

Pry-Out Force - Multi-Shank Ripper with One Tooth81156lbf

Maximum Clearance Raised - Under Tip, Pinned in Bottom Hole34.6in

Number of Pockets3

Weight12136lb

Total Operating Weight* - With SU-Blade and Ripper111739lb

Note* Total Operating Weight includes: single tilt hydraulics, coolant, lubricants, full fuel tank, ROPS, FOPS cab, 610 mm (24 in) ES track shoes and the noted blade and ripper type.

Ground Clearance*18.1in

Track Gauge88.6in

Width - Without Trunnions - Standard Shoe113in

Width - Over Trunnions130.3in

Height - FOPS Cab*150.4in

Height - Top of Stack*152.6in

Height - ROPS/Canopy*157.5in

Drawbar Height (Center of Clevis)*30in

Length - Track on Ground136.6in

Overall Length - Basic Tractor193.3in

Length - Basic Tractor - With Drawbar206.4in

Length - Basic Tractor - With Winch218.3in

Length - With SU-Blade**259.9in

Length - With U-Blade274.3in

Length - With Single-Shank Ripper257in

Length - With Multi-Shank Ripper257.4in

Overall Length - SU-Blade/SS Ripper323.6in

Note (1)*Includes grouser height for total dimensions on hard surfaces.

Winch ModelPA 140VS

Weight*3950lb

Oil Capacity4gal (US)

Drum Width12.6in

Wire Cable Diameter - Recommended1.13in

Wire Cable Diameter - Optional1.25ft

Maximum Drum Capacity - Recommended Cable Length257in

Maximum Drum Capacity - Optional Cable Length204ft

Wire Cable Ferrule Size - Outside Diameter2.4in

Wire Cable Ferrule Size - Length2.8in

Note*Weight shown is base winch only. Does not include mounting arrangement, control arrangement, oil, or wire rope. With counterweight: 3700 kg (8,150 lb).

Note (2)Variable speed, hydraulically driven, dual braking system, three-roller fairlead.

Standard

ROPS/FOPS, Sound-Suppressed Cab

High-Definition Primary Touchscreen Display

Visibility – Rearview Mirrors

Air Conditioner and Heater with Automatic Climate Control

Seatbelt, 76 mm (3 in) Retractable with Switch

Seat — Cloth with Air Suspension

Window Wipers with Wash — Low, High, Intermittent

Differential Steering — Power Turn

Entertainment Radio Ready (12V Power, Harness, Speakers)

Cab Glass — Single-Pane Tinted Safety

Cab Door — Right-Hand Swing

Access/Egress Lighting with Shutdown Timer

"Operator Not Present" Detection

Armrest — Adjustable

Interior LED Courtesy Lights

Interior Backlighting — Dimmable

Air Conditioning Condenser — Cab Mounted (Standard only on Tier 4 engine arrangements. Optional on Tier 2/3 versions. Tier 2/3 versions have underhood A/C condenser standard.)

Decelerator Pedal

Controls — Blade — Electronic

Controls — Ripper — Electronic

Park Brake — Electronic

Engine Speed Control Dial

Cab Access — Blade Pusharm Steps and Grab Handle

Fender Platform Guardrails

Site Communication Radio Mount

Four Fluids (Engine Oil, Coolant, Power Train, Fuel)

Continuous Fluid Level Monitoring — Four Fluids (Engine Oil, Power Train, Coolant, Fuel)

Slope and Side Slope Monitor

Optional

Visibility – Camera – Ripper Tip View

Visibility — Dual Camera

Visibility — Four Cameras — 360-Degree View

Seat — Heated, Cooled, Adjustable Lumbar and Bolsters

Entertainment Radio — AM/FM, Aux Input and Bluetooth®

Cab Glass — Dual-Pane Laminated Impact Safety

Cab Glass — High-Pressure Safety (40 psi/275 kPa)

Window Sunscreen

Small Operator 5th Percentile Mounting Group

Cab Door — Left-Hand Swing

Cab Access — Powered Ladder

Cab Filter Powered Precleaner

Standard

VIMS

Automated Blade Assist (ABA) — When Equipped with Dual Tilt

Cat Product Link Elite (Cellular) (Where Allowed by Local Regulations)

Optional

AutoCarry

Auto Ripper Control

Cat Product Link Elite Dual Mode (Cellular + Satellite)

Cat GRADE with 3D

Standard

Aftercooler, air-to-air

Air filter, with precleaner

Aluminum bar plate radiator, 6 fpi

C18 Tier 4 Final and Stage IV: – 24-volt electric start – Clean Emissions Module

Coolant, extended life

Shift management: - Advanced Productivity Electronic Control System (APECS) - Enhanced AutoShift (EAS)

Engine idle shutdown timer

Ether starting aid, automatic

Fast fuel system

Fuel priming pump, key-on, electric

High speed oil change system, engine and power train

Muffler

Parking brake, electronic

Prescreener

Separator, water/fuel

Three planet, double-reduction planetary final drives

Torque converter

Transmission, electronic control (ECPC), (3F/3R speeds)

Optional

Coolant, arctic

Engine prelube

Exhaust, wrapped: – Insolated Clean Emissions Module

Final drives: – Cold weather – Guarded – Waste handling

Ground level DEF fill

Reversible cooling fan

Standard

Coolant — Extended Life, Standard (— 37° C / — 25° F)

Optional

Coolant — Extended Life, Arctic (— 51° C / — 60° F)

High Ambient Lubrication Package

Arctic Lubrication Package

Standard

Suspension-Type Undercarriage

Track Guide

Two-Piece Master Link

Lifetime-Lubricated Rollers and Idlers

Hydraulic Track Adjusters

Equalizer Bar — Greased End Pin Bearings

Optional

Undercarriage Arrangement — Abrasion

Undercarriage Arrangement — Waste Handling

Undercarriage Arrangement — Cold Weather

Front Striker Bars

Rubber Idler Guards

Track Links — Heavy Duty XL — DuraLink

Track Shoe — Anti-Packing Round Hole Carrier Roller

Carrier Roller

Carrier Roller — Cold Weather

Standard

Electronically Controlled, Load-Sensing Dozer Lift and Tilt

Electronically Controlled, Load-Sensing Ripper Lift and Pitch

Electronically Enabled Blade, Quick Drop

Optional

Dozer Blade Dual Tilt

Ripper Pin Puller

Guarded Tilt Cylinder Lines

Standard

Alternator — 150-Amp

Batteries — 2 x 4, 200-Amp Hour, 12V

12V, 15-Amp Converter

Battery Isolation

Backup Alarm

Lights, Engine Compartment

Lights — Halogen — 8 Positions

Optional

24V Electric Start, Dual Starters

Batteries — 4 x 200, 200-Amp Hour, 12V

Lights — Halogen — 12 Positions

Lights — LED — 14 Positions

Lights — High-Output LED — 14 Positions

Light — Warning Strobe

Standard

Ecology Fluid Drains — All Compartments

Hinged Bottom Guards

High-Speed Oil Change — Engine and Transmission

SOS℠ Fluid Sampling Ports

Diagnostic Connector

CapSureTM Hammerless Ripper Tip and Shank Protectors

Anchorage Points (10)

Optional

Sound-Reduction Sealed Bottom Guards

Ground-Level Fast Fuel Fill (Standard on Tier 4)

Sound Enclosure

Cat Autolube Grease System with Ground-Level Fill and Auto Shutoff

Hinged Quick-Access Door on Radiator Guard

Optional

Ripper Ready

Winch Ready

Ripper — Single Shank

Ripper — Single-Shank Deep

Ripper — Multi Shank (three shank)

Counterweight

Striker Box (Waste)

Winch

Drawbar

Optional

Semi-Universal (13.6 m3/17.8 yd3)

Semi-Universal Abrasion (13.6 m3/17.8 yd3)

Universal (16.6 m3/21.7 yd3)

Universal Abrasion (16.6 m3/21.7 yd3)

Semi-Universal Push Plate (13.6 m3/17.8 yd3)

SU Landfill (28.2 m3/36.8 yd3)

Universal Landfill (38.8 m3/50.8 yd3)

Woodchip (46.1 m3/60.3 yd3)

Coal (36.8 m3/48.2 yd3)
— Some blades only available through Cat Work Tools.
— SU Abrasion and U Abrasion are available with black paint on back side.

Optional

Fire Suppression Ready

Optional

High Debris

Stockpile

Waste Handling

Sound

Arctic

CONTACT US

REQUEST A QUOTE

Complete this form to get a quote on the equipment you are interested in.

    This site is protected by reCAPTCHA and the Google Privacy Policy and Terms of Service apply.

    What You Get: A phone call from a rep or agent. A cost estimate for your machine or the project. An in-person consultation if necessary.
