Net Power - ISO 9249424hp
Net Power - ISO 9249 (DIN)429.9hp (metric)
Engine ModelCat C13
Engine Power - ISO 14396:2002425hp
Engine Power - ISO 14396 (DIN)431hp (metric)
Bore5in
Stroke6in
Displacement763in³
Biodiesel CapabilityUp to B20¹
EmissionsMeets U.S. EPA Tier 4 Final, EU Stage V, and Japan 2014 emission standards.
Note (1)Net power advertised is the power available at the flywheel when the engine is equipped with fan, air intake system, exhaust system, and alternator with engine speed at 1,800 rpm. Advertised power is tested per the specified standard in effect at the time
Note (2)¹Cat diesel engines are required to use ULSD (ultra-low sulfur diesel fuel with 15 ppm of sulfur or less) or ULSD blended with the following lower-carbon intensity fuels** up to: 20% biodiesel FAME (fatty acid methyl ester)* or 100% renewable diesel, HVO
Operating Weight128800lb
NoteVariable Gauge High Wide undercarriage, LRE boom, LRE 8.5B (27'9") stick, HD 1.19 m³ (1.56 yd³) bucket, 900 mm (35") triple grouser shoes, 12.0 mt (26,455 lb) counterweight.
Maximum Digging Depth42.8ft
BoomLRE Boom 11.5 m (37'9")
StickLRE Stick 8.5 m (27'11')
BucketHD 1.19 m³ (1.56 yd³)
Maximum Reach at Ground Level64.4ft
Maximum Cutting Height48.2ft
Maximum Loading Height39.4ft
Minimum Loading Height7.3ft
Maximum Depth Cut for 2440 mm (8 ft) Level Bottom42.5ft
Bucket Digging Force - ISO31700lbf
Stick Digging Force - ISO23380lbf
Maximum Flow - Main System206gal/min
Maximum Pressure - Equipment5076psi
Maximum Pressure - Equipment - Lift Mode5511psi
Maximum Pressure - Travel5076psi
Maximum Pressure - Swing3771psi
Maximum Swing Torque138000ft·lbf
Fuel Tank Capacity188.9gal (US)
Cooling System13.7gal (US)
Engine Oil - With Filter10.6gal (US)
Swing Drive2.8gal (US)
Final Drive - Each2.5gal (US)
Hydraulic System - Including Tank145.3gal (US)
Hydraulic Tank57.3gal (US)
DEF Tank12.2gal (US)
BoomLRE Boom 11.5 m (37'9")
StickLRE Stick 8.5 m (27'11')
BucketHD 1.19 m³ (1.56 yd³)
Shipping Height - Top of Cab11.1ft
Handrail Height11.6ft
Shipping Length54ft
Tail Swing Radius12.3ft
Counterweight Clearance4.7ft
Ground Clearance2.3ft
Track Length17.6ft
Track Length to Center of Rollers14.2ft
Track Gauge10.6ft
Transport Width13.6ft
Air ConditioningThe air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 1.0 kg (2.2 lb) of refrigerant which has a CO2 equivalent of 1.430 metric tonnes (1.576 tons).
