Net Power - ISO 9249201hp
Net Power - ISO 9249 (DIN)204hp (metric)
Engine ModelCat C7.1
Engine Power - ISO 14396:2002202hp
Engine Power - ISO 14396 (DIN)205hp (metric)
Bore4in
Stroke5in
Displacement428in³
Biodiesel CapabilityUp to B20¹
EmissionsMeets U.S. EPA Tier 4 Final, EU Stage V, Korea Stage V, and Japan 2014 emission standards.
Note (1)Net power advertised is the power available at the flywheel when the engine is equipped with fan, air intake system, exhaust system, and alternator with engine speed at 2,200 rpm. Advertised power is tested per the specified standard in effect at the time
Note (2)¹Cat diesel engines are required to use ULSD (ultra-low sulfur diesel fuel with 15 ppm of sulfur or less) or ULSD blended with the following lower-carbon intensity fuels** up to: 20% biodiesel FAME (fatty acid methyl ester)* or 100% renewable diesel, HVO
Operating Weight68100lb
NoteLong undercarriage, Reach boom, R3.2 m (10'6") stick, Heavy Duty (HD) 1.54 m³ (2.01 yd³) bucket, 800 mm (31") triple grouser shoes and 6700 kg (14,770 lb) counterweight.
Maximum Digging Depth23.8ft
BoomReach 6.15 m (20'2")
StickReach 3.2 m (10'6")
BucketHD 1.54 m³ (2.01 yd³)
Maximum Reach at Ground Level35.1ft
Maximum Cutting Height32.9ft
Maximum Loading Height22.8ft
Minimum Loading Height7.5ft
Maximum Depth Cut for 2440 mm (8 ft) Level Bottom23.3ft
Maximum Vertical Wall Digging Depth19.8ft
Bucket Digging Force - ISO40200lbf
Stick Digging Force - ISO28300lbf
Main System - Maximum Flow560 L/min (148 gal/min)
Maximum Pressure - Equipment5075psi
Maximum Pressure - Travel5075psi
Maximum Pressure - Swing4120psi
Swing Speed11.5r/min
Maximum Swing Torque77370ft·lbf
Fuel Tank Capacity125.2gal (US)
Cooling System6.6gal (US)
Engine Oil6.6gal (US)
Swing Drive - Each2.6gal (US)
Final Drive - Each1.5gal (US)
Hydraulic System - Including Tank81.9gal (US)
Hydraulic Tank38.8gal (US)
DEF Tank10.8gal (US)
BoomReach 6.15 m (20'2")
StickReach 3.2 m (10'6")
BucketHD 1.54 m³ (2.01 yd³)
Shipping Height - Top of Cab10ft
Handrail Height10ft
Shipping Length34.2ft
Tail Swing Radius10.3ft
Counterweight Clearance3.7ft
Ground Clearance1.6ft
Track Length15.11ft
Length to Center of Rollers13.1ft
Track Gauge8.6ft
Transport Width10.5ft
Air ConditioningThe air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 0.85 kg (1.9 lb) of refrigerant which has a CO2 equivalent of 1.216 metric tonnes (1.340 tons).
Recyclability97%
