Net Power21hp
Engine ModelC1.1
EmissionsMeets U.S. EPA Tier 4 Final and EU Stage V emission standards.
Bore3in
Engine Power21.6hp
Stroke3.2in
Displacement69in³
NoteNet power advertised is the power available at the flywheel when the engine is at rated speed and rated power when the engine is installed with the factory configured fan, air intake system, exhaust system, and alternator with a minimum alternator load.
Note (1)Advertised power is tested per the specified standard in effect at the time of manufacture.
Operating Weight4222lb
Minimum Operating Weight with Canopy*3946lb
Maximum Operating Weight with Canopy**4222lb
EU: CE Plate Weight***4167lb
Note (2)**Maximum Weight is based on steel tracks, operator, expandable undercarriage and full fuel tank.
Note (1)*Minimum Weight is based on rubber tracks, operator, expandable undercarriage and full fuel tank.
Note (3)***CE Plate Weight is based on the most common EU configuration. Includes 75 kg (165 lb) operator and full fuel tank and excludes bucket.
Dig Depth100in
Tail Swing25.6in
O/A Shipping Height90.6in
Maximum Blade Height10.6in
Minimum Ground Clearance Below Undercarriage5.5in
Boom Height - Shipping Position40.9in
Maximum Dump Clearance98.8in
Track Belt/Shoe Width9.1in
Track Width - Expanded51.18in
Maximum Reach - Ground Level159.8in
Stick Length45.7in
Vertical Wall74.4in
Track Width - Retracted39in
Boom Swing - Right50°
Maximum Reach162.6in
Boom In Reach63.8in
O/A Undercarriage Length62.6in
Overall Shipping Length*141.3in
Maximum Blade Depth10.4in
Maximum Dig Height137.4in
Swing Bearing - Height17.4in
Boom Swing - Left65°
Note*Overall Shipping Length depends on blade position during shipment.
Height8.9in
Note*Expanded – 1300 mm (51 in)
Width*39in
Fuel Tank5.8gal (US)
Engine Oil1.2gal (US)
Hydraulic Tank4.8gal (US)
Cooling System1gal (US)
Hydraulic System6.9gal (US)
Track Belt/Shoe Width9.1in
Track Width - Expanded51.18in
O/A Undercarriage Length62.6in
Maximum Reach - Ground Level153.5in
Boom Height - Shipping Position42.9in
Maximum Reach156.3in
Dig Depth92.5in
Maximum Dump Clearance96.5in
Maximum Blade Height10.6in
Tail Swing25.6in
Boom In Reach64.2in
Minimum Ground Clearance Below Undercarriage5.5in
O/A Shipping Height90.6in
Overall Shipping Length*142.5in
Swing Bearing - Height17.4in
Stick Length37.8in
Vertical Wall70.9in
Boom Swing - Right50°
Track Width - Retracted39in
Maximum Dig Height135in
Boom Swing - Left65°
Maximum Blade Depth10.4in
Note*Overall Shipping Length depends on blade position during shipment.
Auxiliary Circuit - Primary - Pressure3553.4psi
Auxiliary Circuit - Secondary - Pressure3553.4psi
Operating Pressure - Equipment3553.4psi
Auxiliary Circuit - Secondary - Flow3.7gal/min
Auxiliary Circuit - Primary - Flow8.7gal/min
Operating Pressure - Swing2132.1psi
Digging Force - Stick - Long1865.9lbf
Digging Force - Stick - Standard2135.7lbf
Pump Flow at 2,400 rpm17.4gal/min
Digging Force - Bucket3641.9lbf
Operating Pressure - Travel3553.4psi
TypeLoad Sensing Hydraulics with Variable Displacement Piston Pump
Steel Tracks110lb
Long Stick22lb
Heavy Counterweight148lb
Expandable UndercarriageStandard
Maximum Traction Force - High Speed2675.2lbf
Ground Pressure - Minimum Weight4psi
Travel Speed - High2.7mile/h
Ground Pressure - Maximum Weight4.4psi
Travel Speed - Low1.8mile/h
Maximum Traction Force - Low Speed4136.5lbf
Gradeability - Maximum30 degrees
Average Exterior Sound Pressure (ISO 6395:2008)93dB(A)
NoteEuropean Union Directive “2000/14/EC”
Machine Swing Speed9.8r/min
Roll Over Protective Structure (ROPS)ISO 12117-2:2008
Top GuardISO 10262:1998 (Level I)
Tip Over Protective Structure (TOPS)ISO 12117:1997
Recyclability95%
