Net Power45hp
Engine ModelC1.7 Turbo
Gross Power - 2,400 rpm - SAE J1995:201448.4hp
Bore3.3in
EmissionsMeets U.S. EPA Tier 4 Final and EU Stage V emission standards.
Stroke3.9in
Displacement101in³
Net Power - 2,400 rpm - ISO 9249, 80/1269/EEC45hp
NoteNet power advertised is the power available at the flywheel when the engine is at rated speed and rated power when the engine is installed with the factory configured fan, air intake system, exhaust system, and alternator with a minimum alternator load.
Operating Weight9867lb
Minimum Operating Weight with Canopy*8655lb
Maximum Operating Weight with Canopy**9647lb
Note (2)**Maximum Weight is based on steel tracks, operator, full fuel tank, long stick, straight blade, extra counterweight and no bucket.
Note (1)*Minimum Weight is based on rubber tracks, operator, full fuel tank, standard stick, straight blade, no bucket and no extra counterweight.
Maximum Operating Weight with Cab**9867lb
Minimum Operating Weight with Cab*8875lb
Dig Depth138.2in
Maximum Blade Depth18.7in
O/A Shipping Height100in
Maximum Dump Clearance147.2in
Stick Length66.7in
Maximum Dig Height201.8in
Maximum Reach - Ground Level214.4in
Track Width66.9in
Tail Swing with Counterweight51.2in
Swing Bearing - Height21.9in
Boom Height - Shipping Position75.2in
Boom Swing - Left20.9in
Maximum Reach219.3in
Boom In Reach92.1in
Boom Swing - Right28.7in
Track Belt/Shoe Width13.8in
Vertical Wall99.8in
Maximum Blade Height16.5in
Note*Overall Shipping Length depends on blade position during shipment.
Overall Shipping Length*194.9in
Ground Clearance12in
O/A Undercarriage Length87in
Tail Swing without Counterweight47.4in
NoteEuropean Union Directive “2000/14/EC”
Average Exterior Sound Pressure (ISO 6395:2008)97dB(A)
Operator Sound Pressure (ISO 6396:2008)76dB(A)
Maximum Reach - Ground Level204.7in
Vertical Wall94.3in
Note*Overall Shipping Length depends on blade position during shipment.
Tail Swing with Counterweight51.2in
Boom In Reach88.8in
Dig Depth126.4in
Maximum Dig Height198.4in
Maximum Blade Height16.5in
Swing Bearing - Height21.9in
Boom Swing - Left20.9in
Stick Length54.9in
O/A Undercarriage Length87in
Track Belt/Shoe Width13.8in
Boom Height - Shipping Position63.8in
Boom Swing - Right28.7in
Maximum Dump Clearance143.5in
Ground Clearance12in
Maximum Reach209.8in
O/A Shipping Height100in
Tail Swing without Counterweight47.4in
Maximum Blade Depth18.7in
Overall Shipping Length*194.9in
Recyclability96%
Steel Tracks430lb
Counterweight496lb
Angle Blade243lb
Long Stick66lb
Ground Pressure - Minimum Weight4.2psi
Maximum Traction Force - Low Speed7329lbf
Travel Speed - Low2.2mile/h
Ground Pressure - Maximum Weight4.9psi
Travel Speed - High3.2mile/h
Maximum Traction Force - High Speed4271lbf
Gradeability - Maximum30 degrees
Cooling System2.9gal (US)
Engine Oil1.6gal (US)
Hydraulic System17gal (US)
Fuel Tank17gal (US)
Hydraulic Tank14gal (US)
Operating Pressure - Travel3553psi
Auxiliary Circuit - Secondary - Pressure3553psi
Digging Force - Stick - Long4316lbf
Auxiliary Circuit - Secondary - Flow7gal/min
Pump Flow at 2,400 rpm25gal/min
Operating Pressure - Swing2611psi
Auxiliary Circuit - Primary - Flow21gal/min
Auxiliary Circuit - Primary - Pressure3553psi
NoteFlow and pressure are not combinable. Under load, as flow rises pressure goes down.
TypeLoad Sensing Hydraulics with Variable Displacement Piston Pump
Digging Force - Stick - Standard4721lbf
Digging Force - Bucket8588lbf
Operating Pressure - Equipment3553psi
Boom Swing - Right50 Degrees
Machine Swing Speed9r/min
Boom Swing - Left78 Degrees
Angle Blade Height14.2in
Straight Blade Height14.2in
Straight Blade Width66.9in
Angle Blade Width66.9in
Angle Blade - Right25 Degrees
Angle Blade - Left25 Degrees
Roll Over Protective Structure (ROPS)ISO 12117-2:2008
Top GuardISO 10262:1998 (Level I)
Tip Over Protective Structure (TOPS)ISO 12117:1997
