140 Motor Grader LVR

The Cat® 140 Motor Grader combines technology and lever controls for high performance. Integrated technology, such as Cat Grade with Cross Slope and Stable Blade options, ensures optimal grade for your project. The new cab offers increased comfort and ergonomically designed, adjustable control console. Reduce up to 10 percent fuel consumption by using Eco Mode and 20 percent in fluid and filter maintenance costs with the new filtration technology.

Request a Quote

Net Power - EEC 80/1269250hp

Net Power - ISO 9249/SAE J1349250hp

Standard Capability109°F

Engine RPM2,000

Engine ModelCat C9.3

Bore4.5in

EmissionsU.S. EPA Tier 4 Final/EU Stage V

Displacement567.5in³

Stroke5.9in

Number of Cylinders6

Torque Rise - ISO 929444%

Operating Weight - Typically Equipped44613lb

Blade Width12ft

Cutting Edge6in

Arc Radius16.3in

Throat Clearance6.5in

End Bit6in

Air ConditioningThe air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a or R1234yf. See the label or instruction manual for identification of the gas.

Basic Blade Width140in

Length of Machine*397.6in

Width97.6in

Note*Typically equipped with push block and ripper.

Maximum Height132in

Hydraulic System14.5gal (US)

Engine Crankcase7.9gal (US)

Circle Drive1.8gal (US)

Fuel Tank100gal (US)

Front Wheel Spindle Bearing - Each0.13gal (US)

Note*Typically equipped with push block and ripper.

All-Wheel Drive (AWD) Weight44613lb

Maximum Lift Above Ground18.9in

Maximum Depth of Cut28.9in

Standard

Standard and optional equipment may vary. Consult your Cat dealer for details.

Optional

Standard and optional equipment may vary. Consult your Cat dealer for details.

Standard

Vinyl Seat

Information Display Screen

Base cab

Entertainment Radio Ready

HVAC

ROPS, Standard Sound Suppression

Halogen Lighting

Optional

Air Suspension Adjustable Seat

Canopy

Cab Plus

Rear Wiper

Communication Radio Mounting

Rear Window Screen

Defrost Fans

LED Lighting

Standard

Product Link

Optional

Cat Grade with Cross Slope

Cat Grade Attachment Ready Option (ARO)

Cat Grade with Cross Slope Indicate

Digital Blade Slope Meter

Stable Blade

Remote Services

Standard

C9.3

ECO Mode

Optional

Reversing Fan

All-Wheel Drive (AWD)

Standard

Standard Drawbar Circle Moldboard

Circle Drive Slip Clutch

Optional

Top Adjust Drawbar Circle Moldboard

Circle Saver

Standard

Rearview Mirror

Hydraulic Brakes

Secondary Steering System

Signaling/Warning Horn

Side View Mirrors

Optional

Rearview Camera

Standard

Front Bolster

Optional

Counterweight

Push Block

Front Lift Group

Mast Type - Snow Wing

Mast-Less - Snow Wing

Ripper/Scarifier

Auxiliary Hydraulic Lines

Moldboard Extension

Front Blade
