793 Mining Truck

Nominal Rated Payload265ton (US)

Rated Gross Machine Weight890668lb

Chassis Weight295098lb

Body Weight66471lb

Note (1)Consult your tire manufacturer for maximum tire load

Note (2)Chassis weight with full fuel and fluids standard and mandatory attachments hoist body mounting group rims and tires.

Gross Power - SAE J1995:20142650hp

Engine ModelCat® C175-16

Net Power - SAE J1349:20112529hp

Rated Speed1750r/min

Emissions RatingFuel Optimized

Bore7in

Stroke9in

Displacement5187in³

Note (1)Net Power advertised is the power available at the flywheel when the engine is equipped with air intake system exhaust system and alternator.

Note (3)U.S. EPA Tier 4 Final / EU Stage V available for applicable markets.

Front Axle - Empty51%

Rear Axle - Empty49%

Front Axle - Loaded33%

Rear Axle - Loaded67%

NoteDouble reduction planetary with full floating axles.

Differential Ratio1.8:1

Planetary Ratio1

Total Reduction Ratio29

Forward - 18mile/h

Forward - 210mile/h

Forward - 314mile/h

Forward - 419mile/h

Forward - 526mile/h

Forward - 637mile/h

Reverse7mile/h

Top Speed - Loaded37mile/h

Standard Tires737 mm (29 in)

Optional Tires813 mm (32 in)

Tires40.00 R57 46/90 R57 50/80 R57

Note (1)Quick Change Rims optional

NoteExtended life wheel stations optional.

Note (2)Caterpillar recommends the customer evaluate all job conditions and consult tire manufacturer for proper tire selection and TKPH (TMPH) capabilities.

Service BrakesFour-Corner Wet Disc Oil Cooled Hydraulically Actuated

Front Wet Disc Brake Surface Area13907in²

Rear - Wet Disc Brake Surface Area20861in²

Standards(Service and Secondary) ISO 3450:2011

Parking BrakeFour-corner Multi-disc Spring applied Hydraulically Released

Struck112.6-151 m3 (147-197.5 yd3)

Heaped (SAE 2:1)*162-190 m3 (212-249 yd3)

Note (1)Consult your local Cat dealer for body recommendations

TypeTwin two-stage hydraulic cylinders with snubbing valve.

Pump Flow - High Idle216gal/min

Relief Valve Setting - Raise2955psi

Body Raise Time - High Idle22s

Body Lower Time - Float23s

Body Power Down - High Idle21s

TypeSelf-contained nitrogen/oil cylinders pin-to-pin mounting top and bottom double shear clevis attachments

Effective Cylinder Stroke - Front12in

Effective Cylinder Stroke - Rear7in

Rear axle - Oscillation4.9 degrees

Fuel Tank - Optional1300gal (US)

Fuel Tank750gal (US)

Diesel Exhaust Fluid Tank62gal (US)

Cooling System284gal (US)

Crankcase82gal (US)

Front Wheels - Each8gal (US)

Differential - Final Drives260gal (US)

Steering System - Includes Tank77gal (US)

Brake Hoist System - Includes Tank347gal (US)

Torque Converter/Transmission System - Including Sump55gal (US)

Torque Converter Sump27gal (US)

Air Conditioning(HFC - 134A refrigerant) 9.3 kW 31733 BTU/hr

Heater / Defroster36510Btu/h

ROPS Standards (2)ROPS (Rollover Protective Structure) meets ISO 3471:2008 for Operator and ISO 13459:2012 for Trainer

FOPS StandardsFOPS (Falling Objects Protective Structure) meets ISO 3449:2005 Level II for Operator and ISO 13459:2012 Level II for Trainer

NoteAmbient capabilities down to -30C (-22F) for heater/defroster and up to 50C (122F) for air conditioning.

Sound Standards (1)The operator sound pressure level 74 dB(A) complies with ISO 6394 and ISO 6396.

Steer Angle36°

Turning Diameter - Front93ft

Steering StandardsISO 5010:2019

Standard

Alarm, Back-up

Brushless Alternator, 260 ampere

Batteries, 210-amp hour, low maintenance, 12-volt (4)

Converter, 12-volt electrical

Electrical System, 24-volt

Lighting System LED
– Back-up and Hazard Lights
– Directional Signals (front and rear LED)
– Front Stair Access/Service Deck
– Stop/Tail Lights
– Engine Compartment
– VIMS, Blue Light
– Headlights, and fog lights
– Brake and Retarder Light Status Ready

Emergency Engine Shutdown at front bumper and in-cab

Emergency Engine Shutdown at front bumper and in-cab

Optional

Additional Lighting

Jump start Receptacle

Standard

Modular hydraulic powered HVAC with automatic temperature control

Accessory mounting provisions

Coat Hook

Cup Holder

Diagnostic Connection and Service Port

Dome Courtesy Light and Map Lights

Entertainment Radio Ready
Radio mounting provisions and 12V power supply and Wiring Harness, Speakers

Fire Suppression Ready

Gauge/Indicators
– Gauge Panel: Transmission Fluid Temperature, Brake Oil Temperature, Critical oil and Coolant Temperature, Fuel Level (and DEF, if applicable), Operator selectable max. machine speed by rotary dial
– Engine system, brake and transmission fault Indicator
– Electric Hour Meter
– Speedometer
– Tachometer
– Interactive touchscreen vehicle information display: � Day/night mode, � Action alarm, � Quad gauge display

Heater/Defroster

Heated Mirrors, Right and Left

Hoist, Body Control (electric)

Horn

Self-filling to windshield washer fluid from AC condensate

12V auxiliary power connection 5V USB charging port

Cruise Control

Floor mat, multi-piece and replaceable

Delayed engine shutdown

ROPS Cab, Insulated/Sound Suppressed

Seat, Operator, Air Suspension

Seatbelt, Operator, Three Points, Retractable

Seatbelt, Trainer, Two Points, Retractable

Stairway and Walkway Access, 600 mm (24 in)

Steering Wheel, Tilt, Padded, Telescopic

Storage locations for operator gear

Tinted Glass

Transmission Gear Indicator

VIMS Message Center with Advisor

Window, Operator, Electric Powered

Windshield Wiper, Intermittent Control and Washer

Optional

Brake Wear Indicator Gauge

Cabin Filtration System

Electric Powered Window, Right Side

Tank Mud Guards

Cat Next Gen Air Suspension Trainer Seat

Cat Next Gen Heated Operator Seat

Cruise Control

Camera, 360 Surround View

Operator Coaching

AutoHoist

Driver Safety System Mounting

Interface, Third Party

Horn for use in workshop

Mirrors Deluxe

Mirrors, Heated, Wide Body

Retractable Front Sun Visor

Tire shield, air deflector

Standard

Cat C175-16 Engine
– Air Cleaner with Precleaner (4)
– Air-to-Air Aftercooler (ATAAC)
– Automatic Starter Protection
– Multi-Point Oil Pressure Sensing
– Self cleaning oil filter
– Turbocharging (4)/Aftercooled
– Centrifugal oil filter

Braking System
– Automatic Retarder Control, Adjustable
– Brake Release Motor (towing)
– Engine Overspeed Protection
– Extended Life Brake Disc Material
– Oil-cooled, Multi-disc (front and rear)
– Service, Retarding, Parking, Secondary: Park Brake Integrated with Gear Selector, Secondary, Emergency, spring applied with pressure release

Optional

Braking system:
–Anti-lock Braking System (ABS) and Dynamic Stability Control (DSC)

Standard

– 6-speed, Automatic Powershift with APECS controls
– Body-up Reverse Neutralizer
– Body-up Shift Inhibitor
– Controlled Throttle Shifting Directional Shift Management
– Downshift/Reverse Shift Inhibitor
– Lock-up Torque Converter
– Neutral Coast Inhibitor
– Neutral Start Switch
– Programmable Top Speed
– Pre-lubrication/Engine
– Rear Axle Continuous Lubrication/Filtration

Optional

Additional Retarding for Downhill Hauls

High altitude torque converter

Standard

Auto Lubrication System, Auto Shutoff

Aux “Buddy” Dumping Quick Connect

Aux Steering Quick Connect (towing)

Driveline Guard

Fast Fill Fuel System

Fuel Filter with Water Separator

Ground Level Battery Lockout

Ground Level Engine Shut-down

Ground Level Engine Start Lockout

Ground Level lockouts for transmission, battery, and engine

Ground Level VIMS Data Port

Hi-speed Crankcase Oil Change

Hydraulic Filters, 1,000 hour

Battery box, rubber lined

Primary Access Anti-slip High Visibility Demarcations

Reservoirs (3 separate)
– Brake/Hoist, Steering/Fan, Transmission/Converter

Electric Starting System

Rock Ejectors

Engine Delay Shutdown Timer

Service Points, Ground Level

Sight Level Gauges for Hydraulic/Engine Oil/ Torque Converter / Differential

SL-V Grease Injectors

SOS℠ sample ports

Supplemental Steering (automatic)

Tie Down Eyes

Tow Hooks (front)/Tow Pin (rear)

Traction Control System

Vandalism Protection Locks

Standard

Mesabi flexible core radiator

Extended Life Coolant to –35° C (–30° F)

Optional

Antifreeze/coolant protects to –50° C (–58° F)

Optional

Body Heat

Center Tow Bumper Attachment

Air Starting System

Engine Coolant and Oil Heater for Cold Weather Starts

Extended Life Wheel Stations

External Digital Payload Display

Fast Fill Service Center

Fuel Tank (4920 L/1,300 gal)

Hub Odometer (km and miles)

Portable Fire Extinguisher

Rim Guard

Rims (813 mm/32 in)

Reflectors

Walkway and Handrail for Rear Cab Access

Wheel Chocks

Payload digital display

Optional

Command-Ready Option
