Net Power - ISO 924973hp
Engine ModelCat C3.6
Engine Power - ISO 14396:200274hp
Engine Power - ISO 14396 (DIN)75hp (metric)
Net Power - ISO 9249 (DIN)74hp (metric)
Bore4in
Stroke5in
Displacement220in³
Biodiesel CapabilityUp to B20¹
EmissionsMeets U.S. EPA Tier 4 Final, EU Stage V, and Japan 2014 emission standards
Note (1)Net power advertised is the power available at the flywheel when the engine is equipped with fan, air intake system, exhaust system and alternator with engine speed at 2,400 rpm. Advertised power is tested per the specified standard in effect at the time
Note (2)¹Cat diesel engines are required to use ULSD (ultra-low sulfur diesel fuel with 15 ppm of sulfur or less) or ULSD blended with the following lower-carbon intensity fuels** up to: 20% biodiesel FAME (fatty acid methyl ester)* or 100% renewable diesel, HVO
Operating Weight30400lb
Maximum Digging Depth19.8ft
BoomReach 4.65 m (15'3")
StickReach R3.0 m (9'8")
BucketGD 0.53 m³ (0.69 yd³)
Maximum Reach at Ground Level28.4ft
Maximum Cutting Height28.9ft
Maximum Loading Height21ft
Minimum Loading Height5.2ft
Maximum Depth Cut for 2440 mm (8 ft) Level Bottom19.2ft
Maximum Vertical Wall Digging Depth17ft
Minimum Working Equipment Radius8.4ft
Bucket Digging Force - ISO22180lbf
Stick Digging Force - ISO13330lbf
Main System - Maximum Flow247 L/min (65 gal/min)
Maximum Pressure - Equipment5075psi
Maximum Pressure - Travel5075psi
Maximum Pressure - Swing3770psi
Swing Speed11.5r/min
Maximum Swing Torque25888ft·lbf
Fuel Tank Capacity68.2gal (US)
Cooling System4gal (US)
Engine Oil2.1gal (US)
Final Drive - Each0.8gal (US)
Hydraulic System - Including Tank22.5gal (US)
Hydraulic Tank18.5gal (US)
BoomReach 4.65 m (15'3")
StickReach R3.0 m (9'8")
BucketGD 0.53 m³ (0.69 yd³)
Shipping Height - Top of Cab9.2ft
Handrail Height9.2ft
Shipping Length25.5ft
Shipping Length - with Blade26.4ft
Tail Swing Radius7.1ft
Counterweight Clearance3ft
Ground Clearance1.4ft
Track Length12.3ft
Length to Center of Rollers9.9ft
Track Gauge6.5ft
Transport Width8.1ft
Air ConditioningThe air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 0.85 hg of refrigerant which has a CO2 equivalent of 1.216 metric tonnes.
