Net Power - ISO 9249133hp
Net Power - ISO 9249 (DIN)134hp (metric)
Engine ModelCat C3.6
Engine Power - ISO 14396:2002134hp
Engine Power - ISO 14396 (DIN)136hp (metric)
Bore4in
Stroke5in
Displacement220in³
Biodiesel CapabilityUp to B20¹
EmissionsMeets U.S. EPA Tier 4 Final, EU Stage V, Japan 2014 emission standards.
Note (1)Net power advertised is the power available at the flywheel when the engine is equipped with fan, air intake system, exhaust system and alternator with engine speed at 2,200 rpm. Advertised power is tested per the specified standard in effect at the time
Note (2)¹Cat diesel engines are required to use ULSD (ultra-low sulfur diesel fuel with 15 ppm of sulfur or less) or ULSD blended with the following lower-carbon intensity fuels** up to: 20% biodiesel FAME (fatty acid methyl ester)* or 100% renewable diesel, HVO
Operating Weight40200lb
Maximum Digging Depth21ft
BoomReach 5.1 m (16'9")
StickReach R2.9 m (9'6")
BucketGD 0.76 m³ (0.99 yd³)
Maximum Reach at Ground Level29.6ft
Maximum Cutting Height29.1ft
Maximum Loading Height20.6ft
Minimum Loading Height6.5ft
Maximum Depth Cut for 2440 mm (8 ft) Level Bottom20.2ft
Maximum Vertical Wall Digging Depth16.3ft
Minimum Working Equipment Radius9.6ft
Bucket Digging Force - ISO27650lbf
Stick Digging Force - ISO16860lbf
Main System - Maximum Flow296 L/min (78 gal/min)
Maximum Pressure - Equipment5076psi
Maximum Pressure - Travel5076psi
Maximum Pressure - Swing3741psi
Swing Speed8.7r/min
Maximum Swing Torque47647ft·lbf
Fuel Tank Capacity71.6gal (US)
Cooling System5.8gal (US)
Engine Oil2.9gal (US)
Final Drive - Each1.6gal (US)
Hydraulic System - Including Tank24.8gal (US)
Hydraulic Tank23gal (US)
DEF Tank5.9gal (US)
BoomReach 5.1 m (16'9")
StickReach R2.9 m (9'6")
BucketGD 0.76 m³ (0.99 yd³)
Shipping Height - Top of Cab9.6ft
Handrail Height9.6ft
Shipping Length28.1ft
Tail Swing Radius8.2ft
Counterweight Clearance3.3ft
Ground Clearance1.4ft
Track Length13ft
Length to Center of Rollers10.4ft
Track Gauge6.5ft
Transport Width8.8ft
Air ConditioningThe air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 0.9 hg of refrigerant which has a CO2 equivalent of 1.287 metric tonnes.
