Coal HardnessMedium to extremely hard coal
Maximum Installed Power2 × 800 kW (2 × 1,080 hp)
Maximum Cutting Depth8.27in
Mining Height1.1 m-2.3 m (43 in-90 in)
Type of CoalMedium to extremely hard coal
Maximum Plow Speed3.6 m/sec (720 fpm)
Maximum Installed Power2 × 800 kW (2 × 1,080 hp)
Maximum Cutting Depth8.27in
Bottom Bit Positions - Position 1+12 mm (+0.04 ft)
Bottom Bit Positions - Position 4-35 mm (-0.11 ft)
Plow Heights - Height 1980-1230 mm (3.22-4.04 ft)
Plow Heights - Height 31445-1745 mm (4.73-5.73 ft)
Plow Heights - Height 21180-1480 mm (3.87-4.86 ft)
Bottom Bit Positions - Position 2-10 mm (-0.03 ft)
Plow Heights - With Gobside Support1860-2160 mm (6.10-7.08 ft)
Cutting Depth0.69ft
Plow Length9.74ft
Weight5600-8600 kg (12,345-18,960 lb)
Mechanical Height Adjustment180-300 mm (0.59-0.98 ft)
Bottom Bit Positions - Position 3-21 mm (-0.07 ft)
Maximum Drive Power2 × 800 kW (2 × 1,080 hp)
