CPUCat A6 family
Clock FrequencyUp to 260 MHz
Memory8 MB internal FLASH ROM; 32 MB external FLASH ROM
Cores3 core
LED Indication 4 - Key Status - Amount31
LCD Display - Shield Information - Maximum Ratings66 mm (2.6 in) – 320 × 240 pixel – color 64 K in use
LED Indication 1 - Status HMI - Amount3
LED Indication 3 - Big Jumbo LED - Maximum RatingsOn/Off/Blinking – 1 × red, 1 × green, 1 × yellow
LED Indication 3 - Big Jumbo LED - Amount3
Infra-Red LED - Shearer Position Detection - Maximum RatingsIRDA Standard receiver
Note*Radio approval pending.
LED Indication 1 - Status HMI - Maximum RatingsOn/Off/Blinking – 1 × red, 2 × green
LCD Display - Shield Information - Amount1
LED Indication 4 - Key Status - Maximum RatingsOn/Off/Blinking – green
Infra-Red LED - Shearer Position Detection - Amount1
LED Indication 2 - Wireless Status* - Amount2
LED Indication 2 - Wireless Status* - Maximum RatingsOn/Off/Blinking – 1 × green, 1 × yellow
Beeper - Maximum Ratings>= 90 dB
Beeper - Amount1
Length12.36in
Height4.8in
Width4.88in
NoteSKK Connector fits to existing Cat brass bar.
Approximate Weight12.3lb
Supply Voltage - Typical Value12V DC
Supply Voltage - Maximum Ratings9V–13.2V
Power Consumption - Typical Value170mA/@12V
Power Supply Current - Typical ValueNot applicable
Power Supply Current - Maximum Ratings8.1 A (MSHA); 2.5 A (RoW)
Power Consumption - Maximum Ratings230mA/@12V
Operating Temperature - Typical Value68°F
Storage Temperature - Typical Value68°F
Operating Temperature - SymbolTamb
Operating Temperature - Maximum Ratings–20° C–+40° C (–4° F–+104° F)
Storage Temperature - Maximum Ratings–20° C–+60° C (–4° F–+140° F)
Storage Temperature - SymbolT.
SKK 24 mini (Y1-Y6) - Maximum Ratings8 A
SKK 24 mini (X1-X6) - Maximum Ratings8 A
SKK 24 mini (Y1-Y6) - Amount6
SKK 24 mini (X1-X6) - Amount6
