R2900 Underground LHD Loader

Engine ModelCat® C15

Engine Power - Stage V Engine - ISO 14396:2002393HP

Engine Power - Tier 3 Engine - ISO 14396:2002401HP

Engine Power - VR Engine - ISO 14396:2002401HP

Bore5.4in

Stroke6.8in

Displacement927.6in³

Note (1)Power ratings apply at a rated speed of 1,800 rpm for VR and Tier 3 equivalent model when tested under the reference conditions for the specified standard.

Note (2)Power ratings apply at a rated speed of 2,000 rpm for Stage V model engine when tested under the reference conditions for the specified standard.

Note (3)All rating conditions are based on ISO/TR14396, inlet air standard conditions with a total barometric pressure of 100 kPa (29.5 in Hg), with a vapor pressure of 1 kPa (.295 in Hg), and 25° C (77° F). Performance measured using fuel to EPA specifications i

Note (4)Minimal engine derating* required up to 2926 m (9600 ft) at rated speed for Stage V engines, 3048 m (10,000 ft) altitude for Tier 3/Stage IIIA equivalent engines, and 3505 m (11,500 ft) for Tier 2/Stage II equivalent VR engines. (*<5%)

Note (5)Optional Ventilation Reduction Package available.

Note (6)Optional engine with emissions equivalent to Tier 3 and Stage IIIA is also available.

Note (7)Optional engine available that meets U.S. EPA Tier 4 Final and EU Stage V emission standards.

Nominal Payload Capacity37920lb

Gross Machine Mass162736lb

Shipping Mass125203lb

Static Tipping Load - Straight Ahead - Lift Arms Horizontal94106lb

Static Tipping Load - Full Turn - Lift Arms Horizontal80686lb

Breakout Force - Lift (ISO)50062lb

Breakout Force - Tilt (ISO)60298lb

Lift/Tilt System - CircuitOpen Centre, Pilot Control

Lift/Tilt System - PumpFixed Displacement Gear Pump

Maximum Flow at 2,120 rpm116.2gal/min

Relief Valve Setting - Main3408psi

Lift Cylinder - Bore9.1in

Lift Cylinder - Stroke29.4in

Tilt Cylinder - Bore10.5in

Tilt Cylinder - Stroke21.5in

Bucket Capacities6.3-8.9 m³ (8.2-11.6 yd³)

Dump Bucket - 18.2yd³

Dump Bucket - 2 - Standard Bucket9.4yd³

Dump Bucket - 310.9yd³

Dump Bucket - 411.6yd³

Outside Clearance Radius**288.3in

Inner Clearance Radius**133.9in

Axle Oscillation8°

Articulation Angle42.5°

Note**Clearance dimensions are for reference only.

Tire Size29.5 R29

Engine Crankcase9gal (US)

Transmission16.4gal (US)

Hydraulic Tank37gal (US)

Cooling System19.8gal (US)

Front Differential and Final Drives31.4gal (US)

Rear Differential and Final Drives33.5gal (US)

Front Differential and Final Drives - With Axle Oil Cooling System42gal (US)

Rear Differential and Final Drives - With Axle Oil Cooling System44.1gal (US)

Fuel Tank166gal (US)

DEF Tank8.5gal (US)

StandardsROPS/FOPS Certified Cab

Operating Mass*114837lb

Operating Mass* - Front Axle50623lb

Operating Mass* - Rear Axle64214lb

Operating Mass + Rated Payload*152756lb

Operating Mass + Rated Payload* - Front Axle109949lb

Operating Mass + Rated Payload* - Rear Axle42807lb

Note*Calculated Weight.

Raise9.2s

Dump3.4s

Lower, Empty, Float Down3.1s

Total Cycle Time15.7s

Forward - 13.2mile/h

Forward - 26mile/h

Forward - 310.7mile/h

Forward - 418.9mile/h

Reverse - 14.1mile/h

Reverse - 27.5mile/h

Reverse - 313.4mile/h

Reverse - 420.4mile/h

Standard

12V Power Supply in Cab

Alternator, 150-amp

Auxiliary Start Receptacle

Battery Disconnect Switch, Ground Level

Circuit Breaker, 80-amp

Corrosive Protection Spray

Diagnostic Connector

Electric Starting, 24-volt

Engine Shutdown Switches
– Rear Right Hand Side
– Rear Left Hand Side

External LED Lighting System, Front, Rear, Stop light, dual

Low Maintenance Batteries

Reversing Alarm

Starting and Charging System

Standard

Cat Electronic Monitoring System (Cat EMS)

Electric Horns

Gauges
– Engine Coolant Temperature
– Transmission Coolant Temperature
– Hydraulic Oil Temperature
– Fuel Level
– Speedometer
– Tachometer

Indicator Lights
– Alert Warning Light
– Residual Brake Pressure

Low Hydraulic Level Warning

Open Operator Station ROPS/FOPS Structure

Operator Presence System (Auto Park Brake)

Pilot Hydraulic Implement Controls, Single Joystick

Push Button Panel for Lights

Suspension Seat with Retractable Seat Belt

STIC Steering

Standard

Cat C15 ATAAC Diesel Engine, 6-Cylinder

Brake Axle Cooling

Electric Fuel Priming Pump

Engine Air Intake Precleaner

Engine Oil Filter, Remote Mounted

Heat Shields

Long Life Coolant

Planetary Powershift Transmission with Automatic Shift Control, 4 Speed Forward/4 Speed Reverse

Radiator, Cross Flow

Radiator Cap Manual Release

Rims, 5-Piece, Tubeless

SAFR^™ Full Hydraulic Enclosed Wet Multiple-Disc Brakes

Torque Converter with Automatic Lockup Clutch

Transmission Neutralizer

Transmission Filter Drain Tap

Standard

Brake Light

Bucket, Dump

Bucket Lip, Hardox 450 Bucket

Bucket Positioner, Return To Dig

Catalytic Exhaust Purifier/Muffler Group

Decals, International Picto Graphics

Fuel System
– Single Fuel Tank, Bolt-In
– Fuel System Manual Shut Off Taps

Engine and Transmission Belly Guards

Fenders, Front, Rear

Firewall

Handrails
– Hand Hold (Acces On/Off Top Deck)
– Fold Down

Operation and Maintenance Manual – English and other applicable local languages to select

Protection Wear Bars 100 × 50 mm (4 × 2 in)

Semi Centralized Lubrication Points

Rim, 5-Piece, Tubeless

S·O·S port
– Coolant
– Engine Oil
– Hydraulic Oil
– Transmission Oil

Swing Out Radiator Grill

Tires and Rims: A tire must be selected from the mandatory attachments section of the machine price list. Base machine price includes a standard tubeless rim allowance only.

Optional

Battery and Engine Shutdown Switches
– Ground Level Isolation, In Cab Isolation Switch
– Ground Level Isolation, Engine Shutdown Switch
– Ground Level Isolation, In Cab Isolation, Engine Shutdown Switch

Brake Pressure Gauges

Brake Release Arrangements
– Recovery Hook
– Recovery Bar

Buckets
– Various Sizes, Dump (6.3m³/8.2yd³ to 8.9 m³/11.6 yd³)
– Bucket, Light Weight Material (10.5 m³/13.7 yd³ to 11.6 m³/15.2 yd³)
– Bucket Spill Guard

Bucket Hardware
– Cutting Edge, Cat Weld On
– Cutting Edge, Half Arrow, Flat
– Cutting Edge, Bolt-On
– Heel Shrouds
– Mechanical Attached Shroud (MAS)
– Mechanically Attached Wear Plate System, Cutting Edge Protection (MAWPS)
– Mechanically Attached Wear Plate System, Bottom Protection (MAWPS)
– Protector Pads (Bottom of Bucket)
– Wear Bars
– Wear Liner

Bucket Lip
– Lip Fully Welded or Tack Welded
– Lip Bare (No Hardware)

Bolt-On Lip
– MAS Ready (Mechanically Attached Shrouds)

Camera, Color Rear Facing

Cover, Anti Vandalism for Shipping

Draw Bar Attachment, Bolt-On

Engine Options
– Engine, Ventilation Reduction (VR)
– Engine, Equivalent to Tier 3
– Engine, EU Stage V
– After-treatment options (for use with VR Engine only)

• DPF (Flow Through)
• DPF (Wall Flow)

Lighting
– Loading

Fast Fill System
– Fuel
– Coolant
– Engine Oil
– Hydraulic Oil
– Transmission Oil

Fire Suppression System
– Ansul, Wet for Stage V
– Ansul, Wet for VR and Tier 3 equivalent

Fluids
– Arctic Coolant
– Arctic Fuel

Front Light Protectors

Fuel System
– Fuel Lines Double Braided (Stainless Sleeving)
– Fuel Lines Standard Braided (Double Braid Hydraulic Hose)

Guard, Rear Side Quarter Window

Hydraulic System
– Alternate Implement/Pilot Control Configuration

Lubrication System
– Automatic
– Centralized

Operator’s Station, Enclosed ROPS/FOPS
– Air Conditioning
– Cab Pressurizer and Filter
– Dome Light
– Heater
– Radio Ready Compartment for Radio and Speakers

Park Brake Switch Engagement
– Push to Apply
– Pull to Apply

Payload Control System
– Loadrite L2180

Remote Control Interface (excludes Transmitter and Receiver)
– RCT

Radiator
– Standard
– High Efficiency

Reversible Steering

Reflective Tape

Ride Control System

Rim
– Rim Identification Numbering
– Spare (Tubeless)

Seats
– Seat Covers, Tee, Air and Standard
– Suspension Seat Tee, Vinyl
– Suspension Seat Air, Vinyl

Secondary Steering System

Service Tools
– Collet Jacking Bolts
– Recovery Bar (for use with Brake Release, Recovery Bar System)

Switches
– Engine Shutdown, Fire Suppression Activation
– Idle Timer
– Engine Shutdown/Idle Timer

Technology
– Command for Underground
– Wifi (Product Link^™ Elite)

Tire Arrangements
– Tire, 29.5 × R29 VSM L-5S Bridgestone
– Tire, 29.5 × R29 VSDL L-5 Bridgestone

Wear Protection Bars
– Cab/ROPS
– Hydraulic Tank
– Radiator

Windows
– Single Pane
– Dual Pane

NOTE: Not all features are available in all regions. See your Cat dealer for more information.
