CS44B Vibratory Soil Compactor

CS44B Vibratory Soil Compactor

The CS44B provides exceptional performance on flat or sloped terrain. This machine is suitable for many applications from site preparation to compacting sub-bases for parking lots or roadways and is ideal for water and sewer trench work.

Request a Quote

Operating Weight - With Cab15895lb

Weight - Drum with ROPS/FOPS7460lb

Weight - Drum with Cab7756lb

Compaction Width66in

Travel Speed - Maximum7mile/h

Turning Radius - Inside Drum Edge10ft

Static Linear Load - With Cab118lb/in

Ground Clearance16.2in

Static Linear Load - With ROPS/FOPS113lb/in

Gross Power100.6hp

Engine ModelCat C3.4B

Overall Length - With Blade Option18.44ft

Drum Diameter48.1in

Height - With ROPS/FOPS or Cab9.35ft

Overall Width - With Blade Option6.95ft

Optional Blade Height22.6in

Wheel Base8.5ft

Drum Width66in

Overall Length16.7ft

Overall Width5.91ft

Centrifugal Force - Maximum29900lb

Vibratory Frequency - Standard1914V/m

Centrifugal Force - Minimum15000lb

Nominal Amplitude - Low0.033in

Nominal Amplitude - High0.066in

Variable Frequency Option Range23.3-31.9 Hz (1400-1914 vpm)

Tires14.9 × 24 6-ply flotation

Fuel Tank Capacity37gal (US)

Standard

ROPS/FOPS Canopy with Handrails, Floor Mat, Internal Rear View Mirror, Exterior Rear View Mirrors

Vinyl Adjustable Seat with Integrated Console and LCD Display with Lockable Vandalism Guard

Adjustable Tilting Steering Column with Integrated Cup Holders

Rear Vision Camera System

Seat Belt

12-volt Power Outlet

Horn, Backup Alarm

Optional

ROPS/FOPS Cab with Climate Control

Sun Visor

Standard

Smooth Drum

Dual Amplitude, Single Frequency

Pod-Style Eccentric Weight Housings

Auto-vibe Function

Front Adjustable Steel Scraper

Universal Bumper

Optional

Padfoot Shell Kit (oval or square pads available)

Leveling Blade

Variable Frequency

Dual Adjustable Steel Scrapers

Scraper Shell Kit Ready

Recording Module for Vibration Frequency

Standard

Cat C3.4B Engine

Air Cleaner, Dual Element

Two-Speed Throttle Switch, Eco-mode and Automatic Speed Control

Dual Propel Pumps; One for Drum Drive, One for Rear Axle

Fuel Filter, Water Separator, Priming Pump, Water Indicator

Tilting Radiator/Hydraulic Oil Cooler

Dual Braking System

Two-speed Hydrostatic Transmission

Optional

Transmission Guard

Bio-oil Factory Fill

Standard

12 volt Electrical System

150 ampere Alternator

60 Cold-cranking Amps Battery Capacity

Standard

Product Link

Sight Gauges for Hydraulic Oil Level and Radiator Coolant Level

SOS℠ Sampling Valves: Engine Oil, Hydraulic Oil and Coolant

Optional

Upgraded Halogen Light Package

Rotating Beacon

Optional

Measure - Compaction Meter Value (CMV)

Map - SBAS GNSS Mapping

Connect - Cloud and Machine Connectivity
