Rating Prime27 ekW (35 kVA)

Frequency60 Hz

Voltage120 - 600 V

Rating Standby30 ekW (38 kVA)

EngineCat C2.2

FuelDiesel

Height - Without Trailer63.7in

Length - Without Trailer91.3in

Width - Without Trailer41.4in

Weight with Lube Oil and Coolant, Without Trailer2215lb

100% Load 60Hz2.3gal/hr

75% Load 60Hz1.8gal/hr

50% Load 60Hz1.2gal/hr

100% Load 60Hz2.6gal/hr

75% Load 60Hz2gal/hr

50% Load 60Hz1.3gal/hr

Sound Power @ 7 meters (23 feet) @ All Ratings63 dB(A)

Standard

Heavy-duty.
After treatment

Standard

1514J Frame

Standard

XQCP dgital set mounted controller

Standard

Provides package monitoring and management

Standard

Package mounted radiator with vertical air discharge.
Filled from factory

Standard

12V heavy duty starting motor and charging alternator c/w battery isolator

Standard

24 hour dual wall fuel tank with 3 way directional valve for external supply

Standard

Cyclonic/paper with dust cup and service indicator

Standard

Single, robust enclosure for controls and distribution c/w 4 pole circuit breaker and safety cut off

Standard

Heavy Duty steel base frame with integral fuel tank.
Lifting frame and 4 point lift.
base frame is wider than enclosure to protect generator set during transportation

Standard

Sound attenuating, galvanised steel enclosure with exceptional noise reduction performance

Standard

Integrated spark arresting silencer

Standard

On engine primary and secondary oil filters. Filled from factory

Standard

Factory tested and inspected
